Description
10″ x 3″ Ductile Steel V-Groove Wheel
The Ductile Steel wheel provides extreme weight capacity for its size. The ductile steel is graphite-rich, which is stronger and more durable than even our standard semi-steel wheels. With a tensile strength of 45,000 PSI, you’ll be hard-pressed to find a job that needs a stronger wheel. The v-groove allows this wheel to travel along integrated tracks easily.
Tread: Solid Cast Ductile Steel with 7/8″ V-Groove
Core: Solid Cast Ductile Steel
Bearing: Multiple Bearing Options
- Capacity: 7,000 Lbs.
- Color: Red
- Durometer: Shore D 85 (+/-5)
- Temperature Range: -45° F to 250° F
| Load Capacity | 7000 Lbs. |
| Wheel Diameter | 10″ |
| Tread Width | 3″ |
| Tread Type | Solid Cast Ductile Steel with 7/8″ V-Groove |
| Core Type | Solid Cast Ductile Steel |
| Axle / Bore Diameter | -3/4″ (Sealed Precision, Tapered Roller, and Roller Bearing) -1″ (Roller and Tapered Bearing -1-1/4″ (Roller Bearing) |
| Hub Length | 3-1/4″ |
| Bearing Type | – Sealed Precision Ball Bearing -Roller Bearing -Tapered Roller Bearing |
| Wheel Color | Red |
| Durometer | Shore D 85 (+/-5) |
| Temperature Range | -45° F to 250° F |
