Description
5″ x 1-1/4″ Polyon Aluminum Wheel Swivel Caster with Top Lock Brake
Polyurethane elastomer tread chemically bonded to an aluminum core. Aluminum core has a strong attractive appearance, is lightweight and resistant to rust and corrosion.
Tread: Polyurethane Elastomer
Core: Aluminum
Bearing: Ball Bearing
Rig: Zinc-Plated Swivel Caster With Swivel Dust Cap, 2-3/8″ x 3-5/8″ Mounting Plate, Top Lock Brake
- Capacity: 350 Lbs.
- Color: Blue and Silver
- Durometer: Shore A 95 (+/-5)
- Temperature Range: -45° F to 180° F
| Load Capacity | 350 Lbs. |
| Wheel Diameter | 5″ |
| Tread Width | 1-1/4″ |
| Tread Type | Polyurethane Elastomer |
| Core Type | Aluminum |
| Bearing Type | Ball Bearing |
| Wheel Color | Blue and Silver |
| Overall Height | 6-1/8″ |
| Swivel Radius | 4″ |
| Plate Size | 2-3/8″ x 3-5/8″ |
| Bolt Hole Pattern | 1-3/4″ x 2-7/8″ slotted to 3″ |
| Bolt Hole Diameter | 5/16″ |
| Lock Type | Top Lock Brake |
| Durometer | Shore A 95 (+/-5) |
| Temperature Range | -45° F to 180° F |
