Adjustable Category 2 Hydraulic Top Link (24″ to 33 13/16″)

Description

Our Category 2 Hydraulic Top Link with double-piloted check valve prevents cylinder drift and holds cylinder in position. This feature makes our hydraulic top link the best in the market!

Cylinder Features:

Part Number 11239

Category: 2
Pin hole: 1″
Ball width: 2″
Clevis width: 2 1/16″
Distance from center of clevis hole to outer edge: 1 1/4″
Min length: 24″
Max length: 33 13/16″
(Min and max lengths are taken from pin center to pin center)
Stroke: 9 13/16″
Cylinder bore: 3 1/8″
Rod diameter: 1 9/16″

The following two measurements are general guidelines, calculated on a working pressure of 2175 psi:
– Pushing capacity: 17,100 lbs
– Lifting capacity: 12,900 lbs

Double-piloted check valve
Ports 3/8″ BSP (Includes BSP male to NPT male adapters)
Double-acting cylinder
High-quality chrome plated & polished rod
Honed & finished steel tube
Top quality seals
Pressure tested
1 year warranty
Standard color is graphite

Available hydraulic hose kits:

 – kit with 1/2″ valve type couplers – 36″ long
– kit with 1/2″ ball type couplers – 36″ long  – kit with 1/2″ valve type couplers – 24″ long
– kit with 1/2″ ball type couplers – 24″ long
Not sure which top link you need? This article may help: Hydraulic Top Link Cylinders
