Description
Adjustable Span Straddle Powered Stacker with 3″ x 40″ Forks, 1000 lb Capacity
The Adjustable Span Straddle Powered Stacker, available is designed for efficient material handling with a 1000 lb capacity. Featuring a Wesco-manufactured hydraulic cylinder known for proven quality, this stacker includes a battery and charger. The forks lower to the floor on all models for easy loading and unloading of pallets. The extra deep (40″) straddle legs and forks are perfect for lifting pallets, and the versatile adjustable span straddle legs can be set from 34″ to 50″ inside dimensions to handle most standard pallets.
This stacker is equipped with 5″ phenolic front wheels and 4″ phenolic rear swivel casters, ensuring smooth movement and stability. The stacker is available with an optional 110V AC power model upon request and offers a Power Drive option for enhanced performance. It meets ANSI B56.10 specifications, ensuring safety and reliability.
All models come with a 1-year warranty, ensuring reliability and durability in material handling operations.
Specifications
| Specification | Part Number: 261034 | Part Number: 261035 | Part Number: 261036 |
|---|---|---|---|
| Model | PASFL-56-40S | PASFL-64-40S | PASFL-76-40S |
| Type | Adjustable Straddle Fork Models | Adjustable Straddle Fork Models | Adjustable Straddle Fork Models |
| Front Wheel | (2) 5″ Phenolic | (2) 5″ Phenolic | (2) 5″ Phenolic |
| Rear Swivel Caster | (2) 4″ Phenolic | (2) 4″ Phenolic | (2) 4″ Phenolic |
| Lift Height | 56″ | 64″ | 76″ |
| Capacity | 1000 lb | 1000 lb | 1000 lb |
| Width Forks | 3″ | 3″ | 3″ |
| Length Forks | 40″ | 40″ | 40″ |
| Adjustable Base Leg | 34″ to 50″ I.D. | 34″ to 50″ I.D. | 34″ to 50″ I.D. |
| Overall Width | 54″ | 54″ | 54″ |
| Overall Height | 72″ | 80″ | 92″ |
| Overall Depth | 58.75″ | 58.75″ | 58.75″ |
| Weight | 510 lb | 518 lb | 554 lb |
