Description
Fixed Base Powered Stacker with 24″ x 24″ Platform, 1000 lb Capacity
The Fixed Base Powered Stacker is designed for efficient material handling with a 1000 lb capacity. Featuring a Wesco-manufactured hydraulic cylinder known for proven quality, this stacker includes a battery and charger, meeting ANSI B56.10 specifications. An optional 110V AC power model is available upon request.
This stacker is equipped with 5″ phenolic front wheels and 4″ phenolic rear swivel casters, ensuring smooth movement and stability. The platform dimensions and lift heights vary among models, allowing for versatility in different applications. The stacker also offers a Power Drive option for enhanced performance.
All models come with a 1-year warranty, ensuring reliability and durability in material handling operations.
Specifications
| Specification | Part Number: 261022 | Part Number: 261023 | Part Number: 261024 | Part Number: 261025 | Part Number: 261026 | Part Number: 261027 |
|---|---|---|---|---|---|---|
| Model | PESPL-60-2424 | PESPL-68-2424 | PESPL-80-2424 | PESPL-60-3032 | PESPL-68-3032 | PESPL-80-3032 |
| Type | 24″ x 24″ Platform Models | 24″ x 24″ Platform Models | 24″ x 24″ Platform Models | 32″ x 30″ Platform Models | 32″ x 30″ Platform Models | 32″ x 30″ Platform Models |
| Front Wheel | (2) 5″ Phenolic | (2) 5″ Phenolic | (2) 5″ Phenolic | (2) 5″ Phenolic | (2) 5″ Phenolic | (2) 5″ Phenolic |
| Rear Swivel Caster | (2) 4″ Phenolic | (2) 4″ Phenolic | (2) 4″ Phenolic | (2) 4″ Phenolic | (2) 4″ Phenolic | (2) 4″ Phenolic |
| Lift Height | 60″ | 68″ | 80″ | 60″ | 68″ | 80″ |
| Capacity | 1000 lb | 1000 lb | 1000 lb | 1000 lb | 1000 lb | 1000 lb |
| Platform Width | 24″ | 24″ | 24″ | 32″ | 32″ | 32″ |
| Platform Length | 24″ | 24″ | 24″ | 30″ | 30″ | 30″ |
| Load Center | 15″ | 15″ | 15″ | 18″ | 18″ | 18″ |
| Lowered Height | 5.75″ | 5.75″ | 5.75″ | 5.75″ | 5.75″ | 5.75″ |
| Base Leg (ID/OD) | 15″/21″ | 15″/21″ | 15″/21″ | 25.5″/32″ | 25.5″/32″ | 25.5″/32″ |
| Overall Width | 25.5″ | 25.5″ | 25.5″ | 32″ | 32″ | 32.5″ |
| Overall Height | 72″ | 80″ | 92″ | 72″ | 80″ | 92″ |
| Overall Depth | 36″ | 36″ | 36″ | 43.5″ | 43.5″ | 44.5″ |
| Weight | 418 lb | 428 lb | 457 lb | 404 lb | 427 lb | 452 lb |
