Full-Electric Pallet Jack – 4400-Pound Load Capacity

Description

Full Electric Pallet Jack 4400 lbs. Capacity

Effortlessly move heavier loads with these quiet, self-propelled electric pallet trucks. Designed for load and unload delivery and transfer trucks, they free your manpower and increase efficiency. The compact design allows easy maneuverability in narrow warehouses and retail aisles.

The electric pallet jack features push-button lift controls and forward/reverse thumb wheels on an ergonomic handle. The reverse safety switch keeps the operator safe. Quick change and maintenance-free batteries provide up to 5 hours of service per charge and can be changed out in as little as ten seconds, reducing downtime. For convenience, the charger is built into the forklift itself, eliminating additional components.

With a lift range of 3.1″ to 7.5″, polyurethane wheels, and a 180° steering arc, this truck is designed to be used on flat ground, avoiding uneven grounds with potholes or large ramps. The non-marking wheels ensure the floors remain clean.

Compact Maneuverability

• Small Turning Radius and Turtle-mode Upright Movement ensures flexible operation in confined spaces.

Comprehensive Safety Features

• Lifting overload protection
• Emergency power-off
• Emergency reverse via the belly switch
• Height limits

High-Mounted Drive Wheels

• The elevated position of the drive wheels keeps the motor away from ground contaminants like water, dust, and oil, thereby extending its service life.

Enhanced Stability

• A floating balance wheel minimizes lateral sway during operation, ensuring smooth and stable movement.

Durable Hydraulic System

• A large-diameter plunger cylinder operates at low pressure, resulting in reduced failure rates and a longer lifespan for the system.

Environment

• This kind of truck is applicable for goods transportation on hard and flat floor.
• To prolong battery life and ensure proper function, charge once a month when not in use.

Model Number	A-103001
Capacity	4400 lb
Overall length	67.9 in
Overall width	27 in
Overall height	49.2 in
Max lifting height	7.5 in
Fork Length	48 in
Forks Overall width	27 in
Fork thickness	2.1 in
Single fork width	6.3 in
Inside distance between forks	14.4 in
Fork lowered height	3 in
Turning radius	59.5 in
Aisle width	90.9 in
Service weight	530 lb
Driving Speed-laden	2.67 mph
Driving Speed-unladen	2.98 mph
Battery type	Gel Battery
Battery Capacity	105AH
Battery Voltage	24V
Charger	24/10A (built-in)
Lifting distance	4.5 in
Package size	68x27x32in
Gross weight	540 lbs.
Stabilizer Wheel	YES
