Description
Features
Compact and light
Mount weighs only 7.2lb / 3.3kg. You do not need a separate bag for Mount. Just put it in your backpack.
Equatorial / Alt-Az dual Mount
You can easily change to Equatorial mode and Alt-Azi mode. Show your family a star easily in Alt-Azi mode.
Beauty of machined product
Feel the beauty of machined product. All parts of RST-135 are made by machining solid block. The RST-135 is the perfect premium mount.
No need counterweight
You do not need a counterweight to use a 29.7lb / 13.5kg telescope.
Strain wave gear
It is a new type of gear which is widely used in industrial robots. There is no backlash.
Built-in WiFi
This Mount has built-in WiFi. You can control and auto-guide the mount without cable.
Built-in GPS receiver
Built-in GPS receiver eliminates the need to enter the location of the observer.
Built-in Home sensor
Home sensor finds the mechanical origin by itself. This is useful for remote observation.
Specification
- Mount TypeEquatorial / Alt-Az Dual Mount
- Type of GearStrain Wave Gear
- Payload13.5kg (30lbs) – No need counterweight
18kg (40lbs) – Use counterweight - 18kg (40lbs) – Use counterweight
- Slew Speed6º / Second
- Latitude Range0º to 90º
- Power Input12 to 16V DC
- Power Consumption0.2A – Tracking, 16V
3A – Slewing, 16V - 3A – Slewing, 16V
- Weight3.3kg (7.3lbs)
- Size(mm)130 x 120 x 190
- MaterialsAL 6061, Steel, Brass
- ASCOMSupport ASCOM Driver
- Hand ControllerIncluded
- Additional FunctionBuilt-in WiFi
Built-in GPS Receiver
Built-in Home Sensor - Built-in GPS Receiver
- Built-in Home Sensor
