Description
Powered Lift Double Scissors Table with 770 lb Capacity
The Powered Lift Double Scissors Table, model PSLT-770-DS, is designed for efficient material handling with a capacity of 770 lb. This double scissors lift table features 12-volt rechargeable, deep-cycle batteries with an onboard charger and battery gauge, ensuring reliable and continuous operation. The table is equipped with mold-on polyurethane wheels with locking swivel casters for stability and mobility.
Key features include a chrome-plated handle, a keyed on/off switch, a raised-height limit switch, an overload bypass valve, and an emergency stop button for safety. The push-button pendant can be removed for handheld operation, providing versatility and ease of use.
The table size measures 19.625″ in width and 35.875″ in length, with a lift height ranging from 14.5″ when lowered to 51.5″ when raised. The overall depth of the table is 35.875″, and it weighs 300 lb, making it a robust and reliable solution for material handling tasks.
Specifications
| Specification | Part Number: 273713 |
|---|---|
| Model | PSLT-770-DS |
| Capacity | 770 lb (Double Scissor) |
| Caster with Lock | Moldon Polyurethane – 5″ x 2″ |
| Table Width | 19.625″ |
| Table Length | 35.875″ |
| Raised Height | 51.5″ |
| Lowered Height | 14.5″ |
| Table Size | 19.625″ x 35.875″ x 2.25″ |
| Lift Height | 51.5″ |
| Quantity of Batteries | 4 |
| Weight | 300 lb |
